Mitsubishi FX2N-48ET-ESS/UL PLC I/O Expansion Unit
₹18,500
Mitsubishi Electric MELSEC-F FX2N-48ET-ESS/UL is an AC-powered PLC I/O expansion unit designed to expand compatible Mitsubishi FX Series automation systems. It provides 24 digital inputs and 24 transistor/source outputs, with removable terminal blocks and an integrated service power supply. Suitable for industrial machine control and automation applications. Please confirm CPU compatibility and wiring requirements before installation.
SKU: FX2N-48ET-ESS-UL
Mitsubishi FX2N-48ET-ESS/UL PLC I/O Expansion Unit
The Mitsubishi Electric MELSEC-F FX2N-48ET-ESS/UL is a powered
input/output expansion unit designed for compatible Mitsubishi FX
Series programmable controllers. It expands the digital I/O capacity
of an automation system without replacing the main PLC CPU.
Key Features
- 48 integrated I/O points
- 24 digital input points
- 24 transistor/source output points
- 100–240V AC rated power supply
- Built-in 24V DC service power supply
- Removable screw terminal blocks
- Panel and industrial control cabinet applications
Technical Specifications
| Manufacturer | Mitsubishi Electric |
|---|---|
| Series | MELSEC-F / FX2N |
| Model | FX2N-48ET-ESS/UL |
| Unit Type | Powered I/O Expansion Unit |
| Total I/O Points | 48 |
| Inputs | 24 digital inputs |
| Outputs | 24 transistor/source outputs |
| Rated Supply | 100–240V AC |
| Allowable Supply | 85–264V AC |
| Frequency | 50/60 Hz |
| Input Signal | 24V DC ±10% |
| Output External Supply | 5–30V DC |
| Terminal Type | Removable screw terminal block |
| Approximate Weight | 0.85 kg |
Applications
- Industrial machine automation
- Control panels and production lines
- Conveyor and material handling systems
- Digital sensor and actuator interfacing
- Expansion of compatible Mitsubishi FX PLC systems
Compatibility and Installation
Check the main PLC model, available expansion capacity, power supply,
wiring configuration and output load requirements before installation.
The transistor/source outputs require a compatible external DC supply
and correctly designed wiring.
Ordering Information
Please confirm the exact model number and suffix before placing an
order. Product availability, warranty and delivery details should be
confirmed with Nexis Controls before purchase.
| Series | MELSEC-F FX2N |
|---|---|
| Model | FX2N-48ET-ESS/UL |
| Module Type | Powered I/O Expansion Unit |
| Total I/O | 48 |
| Input Points | 24 |
| Output Points | 24 |
| Output Type | Transistor / Source |
| Supply Voltage | 100–240V AC |
